POS Receipt Label Printers

XP-D300M

Front Paper Loading Printer

XP-D300M is high end of thermal printer,designed for vertical printing,wall mountable and customized, not only meet regular POS printing, but also kitchen printing for prevent oil, water and dust.

  • Front paper loading, vertical printing
  • 300MM/S printing speed
  • Serial+USB+Lan interface
  • Built in web page to set up printer directly
  • Printer status monitoring
  • Input buffer 2048K bytes
  • Support QR CODE printing
  • Support LINUX, Windows system
  • Support 58MM and 80MM paper roll printing

Specification

Printing
Printing method Direct thermal
Print width 48mm 76mm
Column capacity 384 dots/line (58mm) 576 dots/line 512 dots/line (80mm)
Printing speed 300mm/s
Interface Serial+USB+Lan
Printing paper 57.5±0.5mm 79.5±0.5mm
Line spacing 3.75mm (Adjustable by commands)

Column number

80mm paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64 columns/
Chinese,traditional Chinese - 21 columns or 24 columns

Character size

ANK,Font A:1.5×3.0mm(12×24 dots) Font B:1.1×2.1mm(9×17 dots) Chinese,traditional Chinese:3.0×3.0mm(24×24 dots)
Cutter
Auto cutter Partial
Barcode Character
Extension character
sheet
PC347(Standard Europe)、Katakana、PC850(Multilingual)、PC860(Portuguese)、PC863(Canadian-French)、PC865(Nordic)、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866(Cyrillic#2)、PC852(Latin2)、PC858、IranII、Latvian、Arabic、PT151(1251)
Barcode types UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128
2D code QR Code
Buffer
Input buffer 2048k bytes
NV Flash 256k bytes
Power
Power adaptor Input:AC 110V/220V, 50~60Hz
Power source Output:DC 24V/2.5A
Cash drawer output DC 24V/1A
Physical characteristics
Weight 1.44KG
Dimensions 144.5×146×188.5mm ( D×W×H)
Environmental Requirements
Work environment Temperature (0~45) humidity(10~80%)
Storage environment Temperature(-10~60℃) humidity(10~80%)
Reliability
Cutter life 1million cuts
Printer head life 100KM
