Description
| Category | Specification | Details |
|---|---|---|
| General | Model | RLS1100B |
| Accuracy Class | Class III | |
| Executive Standard | GB/T 7722-2005 | |
| APHA | 5 Byte | |
| Memory | Flash Memory | External Font 16MB (Master Chip: 512KB) |
| RAM | 8MB | |
| Unit Price Digits | 8 Digits | |
| Weighing | Maximum Capacity | 30 kg |
| Minimum Capacity | 100 g | |
| Verification Scale Interval | 5/10 g (15/30 kg) | |
| Input Sensitivity | ≥ 50 μV/D | |
| Display Resolution | 1/3000 | |
| Measurement Performance | Zero Adjustment Range | ±60 mV |
| Temperature Coefficient (Zero) | ±0.0012% C TYP | |
| Temperature Coefficient (Dead Load) | ±(0.2 μV + 0.0008% of Dead Load) / °C TYP | |
| Nonlinearity | 0.01% F.S. | |
| A/D Conversion Rate | 6 Times per Second | |
| Printing | Printing Method | Direct Thermal Printing |
| Paper Cutting Tool | Sawtooth | |
| Effective Printing Width | 56 mm | |
| Paper Width | 30 – 60 mm | |
| Paper Thickness | 0.05 – 0.5 mm | |
| Resolution | 203 dpi | |
| Print Head Life | 50 km | |
| Printing Speed | 90 mm/s |
