Description
Specifications:
| CPU | ZK Multi-Bio CPU 630 MHz |
| Memory | 256M Flash, 64M SDRAM |
| Hardware Platform | ZEM600 Multi-Medium Development Platform |
| Fingerprint Sensor | ZK Optical Fingerprint Sensor without film |
| Camera | High Resolution Infrared Camera |
| Display | 4.3 inches Touch Screen, Touch Keypad |
| Face capacity | 1200 (1:N) |
| Fingerprint capacity | 2000 |
| ID Card capacity | 10,000 |
| Logs capacity | 100,000 |
| Algorithm Version | ZK Face 7.0 & ZK Finger 10.0 |
| 2000mAh backup battery | Optional |
| Communication | TCP/IP, USB Host, RS232/485, Wiegand Out, Access Control
Interface for 3rd party Electric Lock, Door Sensor, and Exit Button
|
| USB-HOST | Two USB-Host |
| Wireless Wi-Fi | Optional |
| Time attendance Standard functions | ID Card(302 Optional), Automatic Status Switch, Self-Service Query, Work Code, T9 input, 9 digit user ID, DLST |
| Access control interfaces for | 3rd party electric lock, door sensor, exit button |
| Wiegand Signal | Output |
| Optional functions | serial printer, Mifare card, Extendable Scheduled-bell, Short Massage, Web-server, GPRS |
| Power supply | 12V3A |
| Verification Speed | ≤2 sec |
| Operating temp | 0℃- 45 ℃ |
| Operating Humidity | 20%-80% |
| Dimension | 193.6*146.8*111 mm (Length*Width*Thickness) |
| Gross Weight | 1.9 kg |
