| Category | Specification | Details |
|---|---|---|
| Capacity | Fingerprint Capacity | 3,000 (1:N) |
| Transaction Capacity | 30,000 Records | |
| Hardware | Sensor | ZK Optical Sensor |
| Algorithm Version | ZK Finger V9.0 & V10.0 | |
| Display | TFT LCD Color Screen | |
| Interface Styles | Common, Matrix, and Magic Styles | |
| Communication | Communication Ports | RS232/485, TCP/IP, USB Host |
| Wiegand Signal | Input and Output | |
| Access Control Interface | 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell | |
| Functions | Standard Functions | Webserver, Anti-passback |
| Optional Functions | ID Card, Mifare Card | |
| Power & Environment | Power Supply | 12V DC, 3A |
| Operating Temperature | 0°C – 45°C | |
| Operating Humidity | 20% – 80% | |
| Physical | Dimensions (W × D × H) | 87 × 195 × 42.5 mm |
